ROSSLARE AC-825IP IP TABANLI 4 KAPI KONTROL PANELİ
- Açıklama
- Up to 58 doors, 60,000 users, and 500,000 history log entries (FIFO) per ACU
- Onboard TCP/IP networking with AES 128-bit data encryption to an AxTraxNG server, bi-directional push communication for enhanced data transmission speed and reliability
- Supports up to 4 doors (In/Out), each with 2 inputs and 1 output
- 4 auxiliary inputs and 2 auxiliary outputs
- 2 RS-485 buses (OSDP and G-Bus)
- Supports OSDP readers
- One onboard expansion slot and an additional 12 expansion boards via OSDP (R/S/D/P-805)
- R-805 – 16 outputs
- S-805 – 16 inputs
- D-805 – 4-door expansion
- P-805 – 16 inputs and 8 outputs
